Size: 1” (25 mm) standard 1/2” through 3/4” (15 through 20 mm) available on request
Ratings & Connections Flanged: ANSI 150 - 1500
Flangeless for mounting between flanges: ANSI 150 – 2500, UNI-DIN 10 - 400
Screwed: NPT 1/2” through 1” (15 through 25 mm)
Body Materials: stainless steel; monel; hastelloy C; alloy 20
Actuators: integral spring diaphragm
Trim: full stellite needle plug; multistep anti-cavitation trim available
Key features and benefits of the VariPak control valves include:
Heavy Top-Guiding Rugged
Application Flexibility
Adjustable CV
Compact Assembly
Anti-Cavitation Trim
Design flexibility
