Application:
Water and Wastewater Management: Widely used in water distribution, pumping stations, and sewage disposal for their ability to manage large volumes.
HVAC Systems: Used in heating, ventilation, and air conditioning for flow regulation and isolation in cooling towers, boilers, and chillers.
Industrial Processing: Employed in the food, beverage, and chemical industries for controlling fluid flows, often requiring, hygienic, or corrosion-resistant materials.
Oil and Gas/Power Generation: Used in pipelines for high-pressure and high-temperature services (especially double/triple offset types).
Fire Protection: Utilized in firefighting systems and water lines for fire-fighting equipment.
Shipbuilding: Applied in marine applications for seawater management and on-ship piping systems
Class: 150#, 300#, 600#, 900#, 1500#, 2500#Design Standard: API 609 CAT A
Size: 50 mm to 3200 mm
Materials: Body : WCB, CF8, CF8M, Hast Alloy, Super Duplex, Alloy 20 , LCB etc
Disc : WCB, CF8, CF8M, Hast Alloy, Super Duplex, Alloy 20 , LCB etc
Seat : PTFE
Ends: Flanged, Butt Weld , Wafer, Lined, Lugged End
Operation: Manual, Pneumatic, Gear, Actuator
Testing Standard: API 598
